Technical Specifications

Testing Principles:

Through reflection photometer to evaluate the color change of urinalysis  strip,

then calculate the concentration of related items and output  semi-quantitative

results.

Testing Wave Length:

460nm, 550nm, 620nm

Testing Speed: 600 samples / hour

Repeatability: Coefficient of variation CV ≤ 1%

Stability: During 8 hours of operation, Coefficient of variation CV ≤ 1%

Output Options: LCD display, serial port output, Built-in 57mm thermal printer

LCD Screen: 7 inches

Report Storage: Stores up to 9999 sets of results.

External Ports: Type-c X1; USB x2; LAN x1; COMx1

Working Voltage: AC100-240 V 50/60 Hz

Mains supply voltage  fluctuations: ±10%

Overvoltage category: Ⅱ

Dimension: 380 mm x 330 mm x 215 mm (L x W x H)

Power: 45VA

Pollution Degree: 2

Weight: 6.5kg

Product Features

Larger memory with 9999 data recordsTime-saving with a speed of 600

tests/hour

Higher accuracy with black-background test strips

Convenient one-step cleaning with waste tray

Customizable analyte combinations available

Customizable languages with 6 languages prloaded
